GT555
Optional accessories:
Technical features:
GT555 Automatic tyre changer for mounting / demounting and inflation of Car & LCV tyres of wheel rim size 10" - 24" , and for clamping of aluminum alloy rim of 22" size form outside , is designed for mounting / demounting and inflation of tyres of medium and small-scale automobile.
- The plate is enlarged to 24", suitable for mounting/demounting of heavier and wider tire.
- Auxiliary arm system both at left and right side makes the mounting /demounting of wide flat tyre very swift and labor save.
- The air powered tiltable pillar and two pneumatic cylinders for wheel clamping.
- Automatic lifting on the column
- Automatic lifting of the tyre lever , with air buffer
- GT inflates the system to inflate fast for not there is not the inner rube of a tyre tiring in the twinkling of an eye fast.
- Bead breaker designed into two shifts for easy operation.
- The tyre remover which is made of high-quality wear-resisting alloy steel and of perfect and reliable structural design protects steel rim and tyre form any harm in operation.
- The clamping claw which is made of high-quality alloy steel and of scientific structural design protects steel rim from any harm in operation
- The decelerator of precision fabrication, with the worm gear pair made of high-quality special alloy, guarantees the machine wear-resisting and ultra quiet.
- Accessories:two speed Turntable
Technical data:
| Rim clamping from outside | 10”-22” /265 -560mm |
|---|---|
| Rim clamping from inside | 12”-24”/300-610mm |
| Max wheel diameter | 45”/1150mm |
| Max wheel width | 18”/450mm |
| Bead breaker cylinder force | 2500kgf |
| Operating pressure | 8-12 bar |
| Power supply | 220v-1 ph/380V-3PH |
| Motor power | 1.1kw |
| Max rotation torque of turntable | 1100N.m |
| Net weight | 220kg |
| Noise level | <70 dB |
