GA3018
Product Features:
- All-digital 8 beam CCD Wheel Aligner,Zigbee non-obstacle communication, LED electronic level
- Double front axles adjustment, which solve the second axle tyre abrasion problem
- Make measurement for multi-vehicle that includes various heavy trucks,semi-trailer, van,bus, trailer and tractor ect.
- The sensor head structure designed accoring to truck chassis structure, it suits for trucks long wheelbase and large steel rim.
- Sensor heads could interchage, Caster real-time adjustment.
- 16 thousand vehicle data, and will upgrade half a year free.
Standard Configuration:
| Cabinet(trolly) | 1 pc |
|---|---|
| HP Computer | 1 pc |
| 32" LCD Display | 1 unit |
| Printer | 1 pc |
| Sensor heads | 4 pcs |
| 29" alloy truck clamp | 4 pcs |
| Mechanical truck turntable | 2 pcs |
| Steering lock | 1 pc |
| Pedal lock | 1 pc |
Optional Accessory
| Product Photo | Specification, Unit Price ( FOB Dalian) |
|---|---|
|
PDA( wrist-band display) Remote control system of wheel aligner, with the same operation and display functions of wheel alignment, so the users could use it to do complete adjustment for vehicle. |
|
Calibration bench The software program include calibration program,use animation to display the whole calibration procedure, each sep has the clear instruction, easily use. |
|
Adaptor trailer system (Trailer aligning benchmarking stand) It has two ways to locate: Locate the bracket: use electronic center locator to find the traction pin position, it doesn't need to separate vehicle head and trailer; Hang on the trailer center axle: after vehicle head sepearte with trailer, use mechanical clamps to clamp on the traction pin tighty to finish the center location. |
Technical Data
| Measurement | Precision | Measurement Field | |
|---|---|---|---|
| Front Wheel | Toe | ± 1' | ± 12° |
| Camber | ± 1' | ± 10° | |
| Caster | ± 2' | ± 20° | |
| King Pin | ± 2' | ± 20° | |
| Set-back | ± 1' | ± 10° | |
| Rear Wheel | Toe | ± 1' | ± 12° |
| Camber | ± 1' | ± 10° | |
| Set-back | ± 1' | ± 10° | |
| Thrust-angle | ± 1' | ± 10° |
Other Specification
- Temperature: -20°C --- +70°C
- RH: not more than 90%
- Power supply voltage: AC220V±10%
- Ambient pressure: 50/60HZ 70kpa---106kpa
- Charge specification: 7.2V/2400mAH Lithium Battery
- Charge voltage:8.4V
- Charge current: 600Ma (fast), slow (300mA)
- Sensor power: 700mW (operation), 180mW (sleep)
- Complete power consumption: 300W
