GL-3.0HE
GL-3.0HE small platform profile scissor lift can lift each kind of vehicle whose weight is less than 3000kg, suitable for use in vehicle tests, maintenance, wheel alignment and caring for automobiles, which is particularly suitable for use in the basement or on the floor, without construction and hole. The special design's extension board may pick up the major axis distance the vehicle.
Main technical parameter
| Machine type | GL-3.0HE |
|---|---|
| Drive | Electrical hydraulic |
| Max lift weight | 3000kg |
| Main machine lift height | 1850mm |
| Platform initial height | 110mm |
| Platform length | 1450mm |
| Platform width | 635mm |
| Lifting time | ≥50s |
| descent time | ≥60s |
| Whole machine length | 2040mm |
| Whole machine width | 2020mm |
| Whole machine weight | 850kg |
| Power supply | AC 400V or 230V ±5% 50Hz |
| Whole machine power | 2.2kw |
| Hydraulic oil | 12L corresponds to wearable hydraulic oil |
| Gas pressure | 6-8kg/cm2 |
| Working temperature | 5-40°C |
| Working humidity | 30-95% |
| Noisy | <76db |
| Installation height | height above sea level≥1000M |
| Storage temperature | -25°C-55°C |
