GL-4.0DX
GL-4.0DX
>>Anti-slip platform, distance adjustable to accommodate different vehicles. >>The hydraulic cylinder is inside the fixed platform and is thus perfectly protected. >>Safety systems against cable breakage, against obstacles during descend. >>Connected steel cables to force the synchronized moving of platforms. >>Secondary scissor lift for wheel free. >>With sideslip plates and turntable spaces for wheel alignment.
GL4.0DX-1 with Italian pump station, Chinese hydraulic cylinder.
GL4.0DX-2 with Chinese pump station, Chinese hydraulic cylinder.
Technical data
>>Anti-slip platform, distance adjustable to accommodate different vehicles. >>The hydraulic cylinder is inside the fixed platform and is thus perfectly protected. >>Safety systems against cable breakage, against obstacles during descend. >>Connected steel cables to force the synchronized moving of platforms. >>Secondary scissor lift for wheel free. >>With sideslip plates and turntable spaces for wheel alignment.
GL4.0DX-1 with Italian pump station, Chinese hydraulic cylinder.
GL4.0DX-2 with Chinese pump station, Chinese hydraulic cylinder.
Technical data
|
Lifting capacity |
4000kg |
First raising time |
≤80s |
|
Secondary lifting capacity |
2000kg |
First lowering time |
≤70s |
|
First lifting height |
1550mm |
Secondary raising time |
≤30s |
|
Secondary lifting height |
300mm |
Secondary lowering time |
≤30s |
|
Min. height |
255mm |
Motor power |
3kw/2.2kw |
|
Net weight |
1300kg |
Power supply |
380v/50Hz |
