GT855
Optional Accessories:
Technical features:
GT855 automatic Tire Changer for mounting/demounting and inflation of Car & LCV tires of wheel rim size 10"-24" and for clamping of aluminum alloy rim of 22" size from outside, is designed for mounting/demounting and inflation of tire of medium and small-scale automobile.
- The plate is enlarged to 24", suitable for mounting/demounting of heavier and wider tire.
- Equipped with a double speed engine(May elect), the rotating speed of the plate can be adjusted automatically in changing tire which saves more time.
- Auxiliary arm system makes the mounting/demounting of wide flat tire very swift and labor save.
- The air powered tiltable pillar and two pneumatic cylinders for wheel clamping.
- GT express inflating system can inflate the inner tube of a tire in an instant.
- The self-centering makes it swift and convenient to operate.
- The tire remover which is made of high-quality wear-resisting alloy steel and of perfect and reliable structural design protects steel rim and tire from any harm in operation.
- The clamping claw which is made of high-quality alloy steel and of scientific structural design protects steel rim from any harm in operation.
- Accessories:two speed Turntable
The decelerator of precision fabrication, with the worm gear pair made of high-quality special alloy, guarantees the machine wear-resisting and ultra quiet.
Technical data:
| Rim clamping from outside | 10”-22”/265-560mm |
|---|---|
| Rim clamping from inside | 12”-24”/300-610mm |
| Max wheel diameter | 45”/1150mm |
| Max wheel width | 16.5”/420mm |
| Bead breaker cylinger | 2500kgf |
| Operating pressure | 8-12 bar |
| Power supply | 220v-1ph/380V-3ph |
| Motor power | 1.1 kw |
| Max rotation torque of turntable | 1100 N.m |
| Net weight | 220kg |
| Noise level | <70 dB |
